Technical Specifications
GENERAL
Credentials Supported
- FIngerprint and RFID Card
RF Option
- COSEC PATH RDFE:- EM Proximity Card
COSEC PATH RDFM:- MIFARE Classic®, DESFire EV1 and EV2(Read/Write)/ NFC Tag
COSEC PATH RDFI:- HID i-Class/ Mifare/ Desfire/ Combo Cards*MIFARE and MIFARE Classic® are trademarks of NXP B.V.
CAPACITY
Template Capacity
- 9,600 (1:N Mode)
Event log
- No
COMMUNICATION
RS-485
- Yes
RS-232
- Yes
HARDWARE
Reset Switch
- Yes
Tamper Detection
- Yes
SENSOR
Sensor Name
- Suprema Sensor
Sensor Technology
- Optical
Encryption
- 256-bit AES
Water-proof
- Yes
False Acceptance Ratio (FAR)
- 0.00001
False Rejection Ratio (FRR)
- 0.0001
Resolution (DPI)
- 500 dpi
Sensing Area
- 16.00mm x 19.00mm
Template Size
- 384 Bytes
Image Size (Pixel)
- 272mm x 320mm
AUDIO VISUAL
LED
- Yes (Tri Color)
Buzzer
- Yes (61 dbA@30cm)
ENVIRONMENTAL
Operating Temperature
- 0 °C to +50°C (32°F to 122°F)
Relative Humidity
- 5% to 95 % RH Non-Condensing
POWER
Power
- 12 VDC @ 0.1A
MECHANICAL
Dimensions
- 50mm x 136mm x 33mm
Weight
- 0.27 Kgs (0.59 lbs)
Ingress Protection
- IP65
INSTALLATION
Mounting
- Vertical wall mounting
Technical Specifications
GENERAL
Credential Support
- BLE and Card
RF Option
- COSEC ATOM RD100E:- EM Proximity Card
COSEC ATOM RD100M:- MIFARE Classic®, DESFire EV1 and EV2(Read/Write)/ NFC Tag
COSEC ATOM RD100I:- HID i-Class/ Mifare/ Desfire/ Combo Cards*MIFARE and MIFARE Classic® are trademarks of NXP B.V.
CAPACITY
User Profile
- Depends on the Master Device
Event Log
- Depends on the Master Device
COMMUNICATION
Inbuilt Bluetooth®
- Yes
INTERFACE
RS-232
- Yes (Compatible with COSEC ARGO, COSEC VEGA, COSEC PATH V2)
Wiegand
- Yes
RS-485
- Yes (Compatible with ARC DC200P)
HARDWARE
Dimensions
- 101mm X 60 mm X 19mm
Weight
- 0.14kgs (0.30 Lbs)
Gorilla Glass
- Yes (Gorilla Glass 3)
CPU
- Nordic 32 Bit
Tamper Detection
- Yes
Buzzer
- Yes (12V Magnetic buzzer)
LEDs
- Yes (Tri Color)
Ingress Protection (IP)
- Yes (IP65)
Vandal Proof (IK)
- Yes (IK07)
Keypad
- No
ENVIRONMENTAL
Operating Temperature
- 0°C to +55°C
Humidity
- 5% to 95 % RH Non-Condensing
INSTALLATION
Wall Mount
- Yes
Technical Specifications
GENERAL
Communication mode
- Ethernet & RS-485
Event buffer
- 100,000
COMMUNICATION
Ethernet
- Yes (10/100 Mbps)
RS-485
- Yes
POE
- Yes (IEEE 802.3 af)
INTERFACE
AUX IN
- 8 Input Port
AUX OUT
- 8 Output Port
AUX IN Type
- 4 State supervised
AUX OUT Type
- 28VDC @2A (Relay SPDT, FORM C)
HARDWARE
CPU
- PIC32 Microcontroller
Flash memory
- 512 Kbytes
RAM memory
- 128 Kbytes SRAM
Reset switch
- Yes (for making device default)
AUDIO VISUAL
LED
- 1 Dual color LED
Buzzer
- Yes
ENVIRONMENTAL
Operating Temperature
- 0°C to +50°C (32°F to 122°F)
Relative Humidity
- 20% to 95 % RH Non-Condensing
POWER
Power
- Adaptor = 12 VDC @ 2 A
- PoE = 12 VDC @1 A”
MECHANICAL
Dimensions
- 107 mm x 125.5 mm x 55 mm
Weight
- 0.26 Kgs (0.57 lbs)
COMPATIBILITY
System Integration
- API for Software integration
Operational Mode
- Direct/Panel door with COSEC CENTRA/ VYOM
Panel door with Standalone COSEC PANEL200
GENERAL
Communication mode
- Ethernet & RS-485
Event buffer
- 100,000
COMMUNICATION
Ethernet
- Yes (10/100 Mbps)
RS-485
- Yes
POE
- Yes (IEEE 802.3 af)
INTERFACE
AUX IN
- 8 Input Port
AUX OUT
- 8 Output Port
AUX IN Type
- 4 State supervised
AUX OUT Type
- 28VDC @2A (Relay SPDT, FORM C)
HARDWARE
CPU
- PIC32 Microcontroller
Flash memory
- 512 Kbytes
RAM memory
- 128 Kbytes SRAM
Reset switch
- Yes (for making device default)
AUDIO VISUAL
LED
- 1 Dual color LED
Buzzer
- Yes
ENVIRONMENTAL
Operating Temperature
- 0°C to +50°C (32°F to 122°F)
Relative Humidity
- 20% to 95 % RH Non-Condensing
POWER
Power
- Adaptor = 12 VDC @ 2 A
- PoE = 12 VDC @1 A”
MECHANICAL
Dimensions
- 107 mm x 125.5 mm x 55 mm
Weight
- 0.26 Kgs (0.57 lbs)
COMPATIBILITY
System Integration
- API for Software integration
Operational Mode
- Direct/Panel door with COSEC CENTRA/ VYOM
Panel door with Standalone COSEC PANEL200
Technical Specifications
GENERAL
Reader Interface
- RS-485 & Wiegand
Reader on RS-485
- 2 (MATRIX Reader – COSEC PATH RDXX, COSEC ATOM 100/200/300)
Reader on Wiegand
- 2 (Any Third party reader)
Maximum Doors
- 2 doors/Locks
Reader Distance
- 1220 meters (on RS-485) &
100 meters (on Wiegand)
CAPACITY
User Profile
- 50,000
Event Log
- 5,00,000
COMMUNICATION
Inbuilt Wi-Fi
- YES (IEEE 802.11 b/g/n)
Inbuilt BLE
- YES (Configurable range: 1m – 8m)
Ethernet
- YES (10/100 Mbps)
RS-485
- YES
POE/ POE+
- YES (IEEE 802.3 af/at)(PoE/PoE+)
- PoE = up to15.4 W
- PoE+ = up to 25.5 W
Wiegand
- Yes (Selectable IN/OUT)
IN: 26 Bit format
OUT: Configurable
INTERFACE
Exit Switch interface
- YES
Door Status Sense
- YES (4 State – Programmable NO, NC and Supervised)
Door Lock Relay
- Yes (30VDC @2A, Dry Contacts NO/NC/COM)
AUX IN
- YES (4-state)
AUX OUT
- Yes (Max. 30VDC @ 2A)
HARDWARE
CPU
- Cortex A8 800 MHz
Operating System
- Linux based OS
Flash memory
- 256 MB
RAM memory
- 256 MB (DDR3 SDRAM @800MHz)
Reset switch
- YES (for making device default)
AUDIO VISUAL
LED
- 1 Tri color LED
Buzzer
- YES
ENVIRONMENTAL
Operating Temperature
- -10°C to +50°C (14°F to 122°F)
Relative Humidity
- 5% to 95 % RH Non-Condensing
POWER
Power
- Adaptor = 12 VDC @ 2 A
- PoE+ = 12 VDC @1.8 A
Power to Door Lock
- With PoE: 12VDC@ 0.5A for 1 Lock
- With PoE+ : 12VDC @ 1A For 1 lock or
- 12VDC @ 0.5A for 2 Lock ( 0.5A EACH LOCK)
- Adapter : 12VDC@ 0.5A at 1 Lock
Reader Power Output
- Max 12VDC @ 0.250A (on external supply or PoE/PoE+)
MECHANICAL
Dimensions
- 140mm x 24mm x 80mm
Weight
- 0.23 Kg (0.507 lbs)
Enclosure material
- Metal Aluminium Casing (Black)
COMPATIBILITY
System Integration
- API for Software integration
Operational Mode
- Direct/Panel door with COSEC CENTRA/ VYOM
- Panel door with Standalone COSEC PANEL200
INSTALLATION
Mounting
- Wall mounting with L shape hinge and Din rail mounting provision
Technical Specifications
CAPACITY
Maximum Door Controllers
- 255
Door controller on RS-485
- 32
Max User Capacity
- 25,000
Event Buffer
- 5,00,000
COMMUNICATION
Wi-Fi
- Inbuilt Wi-Fi Module (IEEE 802.11 b/g/n)
Inbuilt Bluetooth
- YES
Ethernet
- YES (10/100 Mbps)
RS-485
- YES
USB
- One USB Port (For data transfer and 2G-3G-4G /WiFi Dongle)
SD Card
- YES (8 GB)
INTERFACE
Aux-In
- YES (4 states – short, open, activated & non-activated)
Aux-Out
- Form C and SPDT Relay
HARDWARE
CPU
- Cortex A8 800 MHz
Flash memory
- 256 MB
RAM memory
- 256 MB (DDR3 SDRAM @ 800MHz)
Operating system
- Linux based OS
Communication Port
- Ethernet & RS-485
Tamper Detection
- YES
RTC
- YES
AUDIO VISUAL
LED
- Tricolor LED (Power, Status & Alarm)
Buzzer
- YES (12V)
ENVIRONMENTAL
Operating Temperature
- -10°C to +55°C (14°F to 131°F)
Humidity
- 5% to 95 % RH Non-Condensing
POWER
Input Power
- External Power Adapter 12 VDC @ 2 A
MECHANICAL
Dimensions (L x H x D)
- 125.25mm X 81.5mm X 30.5mm (4.93” x 3.20” x 1.20”)
Weight
- 140gm (0.308 lbs)
Enclosure material
- ABS V0 grade
CERTIFICATES
Certificates
- FCC, CE, and RoHS
COMPATIBILITY
System Integration
- API for Software integration
Architecture
- 1) Network Architecture – With COSEC CENTRA/VYOM
- 2) Standalone Architecture
OTHER Details
Mounting
- Wall Mounting or Tabletop
Packaging Content
- 1) Main unit
- 2) Adaptor (12VDC, 2A)
- 3) SD Card (8 GB)
Technical Specifications
GENERAL
Credential Support
- Bluetooth® (BLE), Fingerprint, and RFID Card
Ingress Protection
- IP65
Card
- COSEC PATH DCFE:- EM Proximity Card
COSEC PATH DCFM:- MIFARE Classic®, DESFire EV1 and EV2(Read/Write), NFC Tag
COSEC PATH DCFI:- HID iClass Card Support (Read/Write), HID Prox, EM Prox, Desfire EV1 & EV2 (CSN Read) and Mifare Classic (CSN Read) , NFC Tag*MIFARE and MIFARE Classic® are trademarks of NXP B.V.
CAPACITY
Max. Users
- 50,000
Max. Template Storage
- 25,000 in 1: N Mode and 100,000 in 1:1 Mode
Event Buffer
- 500,000
Templates per User
- Up to 10 (Single Template per Finger Mode)
- Up to 5 (Dual Template per Finger Mode)
COMMUNICATION
Wi-Fi
- Yes
Bluetooth®
- Yes
Ethernet
- Yes (10/100 Mbps)
PoE
- Yes (IEEE 802.3 af)
RS-232
- Yes
RS-485
- Yes
Wiegand
- Yes (Selectable IN/OUT)
IN: 26 Bit format
OUT: Configurable
INTERFACE
Exit Switch Port
- Yes
Door Status Sense
- Yes(2State)
Door Lock Relay
- Yes
Door Lock Power
- 12V DC @ 0.5A (Power to External Lock from Device)
- 30V DC @ 1A (Power to Lock from External power source)
Aux-In
- No
Aux-Out
- No
Reader Interface Types
- RS-232 and Wiegand
HARDWARE
CPU
- 800 MHz ARM Cortex A8 based Processor
Memory
- 512 MB Flash + 512 MB DDR3 RAM
LED
- Yes
Buzzer
- Yes
Operating Temperature
- 0°C to +50°C (32°F to 122°F)
Humidity
- 5% to 95% RH Non-Condensing
Tamper Detection
- Yes
Power
- 12V DC @ 2A
Power to Door Lock
- 12V DC @ 0.5A (Power to Lock from Device)
Dimensions (WxHxD)
- 50mm x 159mm x 42mm
Weight
- 0.375Kgs (0.82Lbs)
COMPATIBILITY
System Integration
- API for Software Integration
Operational Modes
- Direct Door with COSEC CENTRA / COSEC VYOM
- Panel Door with COSEC PANEL200P
SENSOR
Sensor Name
- Suprema Optical Sensor – SFM6030
Sensor Technology
- Optical Technology
Encryption
- 256-bit AES
Waterproof
- Yes
False Acceptance Ratio (FAR)
- 0.001%
False Rejection Ratio (FRR)
- 0.010%
Resolution (dpi)
- 500
Sensing Area
- 16.0mm x 18.0mm
Template Size
- 384 bytes
Image Size
- 272mm x 320mm
INSTALLATION
Wall Mount
- Yes
ACCESSORIES
Power Adapter
- 12VDC @ 2A (CE, FCC, UL, BIS)
Battery Backup
- Yes (External- 6hrs of Battery Backup on COSEC PATH BBU & COSEC PATH PSBB)
Technical Specifications
GENERAL
Credential Support
- Bluetooth® (BLE), Fingerprint, RFID Card, PIN, Face (with Compatible Hardware)
Ingress Protection
- IP65
Card
- COSEC VEGA FAE:- EM Proximity Card
COSEC VEGA FAM:- MIFARE Classic®, DESFire EV1 and EV2(Read/Write), NFC Tag
COSEC VEGA FAI:- HID iClass Card Support (Read/Write), HID Prox, EM Prox, Desfire EV1 & EV2 (CSN Read) and Mifare Classic (CSN Read), NFC Tag*MIFARE and MIFARE Classic® are trademarks of NXP B.V.
CAPACITY
Max. Users
- 50,000
Max. Template Storage
- 9,600 in 1: N Mode and 100,000 in 1:1 Mode
Event Buffer
- 500,000
Templates per User
- Up to 10 (Single Template per Finger Mode)
- Up to 5 (Dual Template per Finger Mode)
COMMUNICATION
Wi-Fi
- Yes
Bluetooth®
- Yes
Ethernet
- Yes (10/100 Mbps)
PoE
- Yes (IEEE 802.11 b/g/n)
RS-232
- Yes
Mobile Broadband
- Yes (3G/4G/LTE)
Wiegand
- Yes (Selectable IN/OUT)
IN: 26 Bit format
OUT: Configurable
USB
- 1 USB Port (Data Transfer and 3G/4G/LTE Dongle)
INTERFACE
Exit Switch Port
- Yes
Door Status Sense
- Programmable NO, NC, Supervised
Door Lock Relay
- 30V DC @ 1A, Form C, DPDT Relay
Door Lock Power
- 12V DC @ 0.5A (Power to external Lock from Device)
- 30V DC @2 A (Power to lock from External power source)
Aux-In
- Yes
Aux-Out
- Yes
Reader Interface Types
- RS-232 and Wiegand
HARDWARE
CPU
- 800 MHz ARM Cortex A8 based Processor
Memory
- 256 MB Flash + 512 MB DDR3 RAM
Micro SD Card
- Yes (Inbuilt 16 GB)
Display
- 3.5″ TFT Display with Capacitive Touch Panel
Display Resolution
- 320 x 240 Pixel
Buzzer
- Yes
Operating Temperature
- 0°C to +50°C (32°F to 122°F)
Humidity
- 5% to 95% RH Non-Condensing
Tamper Detection
- Yes
Power
- 12V DC @ 2A
Power to Door Lock
- 12V DC @ 0.5A (Power to Lock from Device)
Dimensions (WxHxD)
- 91mm x 186mm x 38mm
Weight
- 0.54Kgs (1.19Lbs)
COMPATIBILITY
System Integration
- API for Software Integration
Operational Modes
- Direct Door with COSEC CENTRA / COSEC VYOM
- Panel Door with COSEC PANEL200P”
SENSOR
Sensor Name
- Suprema Optical Sensor – SFM6030
Sensor Technology
- Optical Technology
Encryption
- 256-bit AES
Waterproof
- Yes
False Acceptance Ratio (FAR)
- 0.001%
False Rejection Ratio (FRR)
- 0.001%
EER
- <0.08%
Resolution (dpi)
- 500
Sensing Area
- 16.0mm x 18.0mm
Template Size
- 384 bytes
Finger Duress Detection
- Supported (Direct/Panel Door)
INSTALLATION
Wall Mount
- Yes
ACCESSORIES
Power Adapter
- 12VDC @ 2A (CE, FCC, UL, BIS)
Battery Backup
- Yes
Technical Specifications
CREDENTIAL SUPPORT
Face
- Yes
PIN
- Yes
Card
- COSEC ARGO FACEE:- EM Proximity Card
COSEC ARGO FACEM:- MIFARE Classic®/Desfire/NFC Tag
COSEC ARGO FACEI:- HID i-class, HID Prox,EM Prox & Mifare/Desfire/NFC Tag*MIFARE and MIFARE Classic® are trademarks of NXP B.V.
BLE – Mobile
- Yes
CAPACITY
User Profiles
- 50,000
Face Templates
- 200,000
Max. Templates Per User
- 30
Event Logs
- 500,000
FACE RECOGNITION
Algorithm
- Deep Learning based Face Recognition
Fake Face Detection
- Yes
Face Identification
- 1:200,000 in < 1 sec
- 1:1 in < 0.5 sec
Face Enrolment
- Face Recognition Terminal
- Enrolment Station
- Upload Images
- Exception Faces
GENERAL SPECIFICATIONS
Dimensions (WxHxD)
- 74 mm x 186mm x 50mm
Weight
- 0.65Kgs (1.433 lbs)
Display
- 3.5″ IPS LCD (Touch Screen)
Display Resolution
- 480 x 320 Pixel
- Yes (Gorilla Glass 3)
Gorilla Glass
- Yes (Gorilla Glass 3)
CPU
- Quad Core ARM Cortex-A7 @ 1.5 GHz
GPU
- Built-in 2 TOPS Neural Network Computing Performance
RAM
- 2 GB DDR4
Flash Memory
- 16 GB eMMC16 GB eMMC
SD Card
- No (Built-in 16GB eMMC provided)
Tamper Detection
- Yes
Buzzer
- Yes
IR LEDs
- Yes
Ingress Protection
- IP65
Vandal Protection
- IK06
Certificate
- CE, FCC, BIS, UL, RoHS
Operating Temperature
- 0°C to +50°C (32°F to 122°F)
Storage Temperature
- -20°C to 60°C
Humidity
- 5% to 95 % RH Non-Condensing
CAMERA
RGB Camera
- 2MP Surveillance Grade, IR Blocked
Infrared Camera
- 2MP Surveillance Grade, IR Band Pass
Camera Sensors
- SONY IMX 307, EXMOR Technology, STARVIS Series
COMMUNICATION
Ethernet
- Yes (10/100 Mbps – 1 port)
PoE
- Yes (IEEE 802.3 af)
WiFi
Yes (802.11 b/g/n)
3G/4G/LTE
- Yes (Additional USB Modem)
BLE
- Yes (Version4.2) (8m Range)
USB
- Yes (USB 2.0)
- Micro USB-Type B
INTERFACE
Exit Switch Interface
- Yes
External Reader Support
- Yes (MATRIX and 3rd Party)
External Reader
- Interface
- RS232
- Wiegand
- Power
- 12VDC @ 0.5A
- LED and Buzzer Control
- Allowed – GREEN LED
- Buzzer
Wiegand
- Yes (Selectable IN/OUT)
IN: 26 Bit format
OUT: Configurable
Door Lock Relay
- Yes (30VDC @ 2A, Dry Contacts NO/NC/COM)
Door Lock Power
- Internal PoE Power: 12VDC @ 0.250 A
- Internal Adapter Power 12VDC @ 0.5 A
- External Power 12VDC @ 2A
INSTALLATION
Wall Mount
- Yes – Plastic Back Cover with Screws
Flush Mount
- Yes – Metal Bracket with Screws
ACCESSORIES
Power Adapter
- 12VDC @ 2A (CE, FCC, UL, BIS)
Technical Specifications
GENERAL
Credential Support
- Bluetooth® (BLE), Fingerprint, RFID Card, PIN, Face (with Compatible Hardware)
Ingress Protection
- IP65
Vandal Protection
- IK07
Card
- COSEC ARGO FOE:- EM Proximity Card
COSEC ARGO FOM:- MIFARE Classic®, DESFire EV1 and EV2(Read/Write), NFC Tag
COSEC ARGO FOI:- HID iClass Card Support (Read/Write), HID Prox, EM Prox, Desfire EV1 & EV2 (CSN Read) and Mifare Classic (CSN Read) , NFC Tag*MIFARE and MIFARE Classic® are trademarks of NXP B.V
CAPACITY
Maximum Users
- 50,000
Maximum Templates
- 25,000 in 1: N Mode
- 100,000 in 1:1 Mode
Event Buffer
- 500,000
Templates per User
- Up to 10 (Single template per finger mode)
- Up to 5 (Dual template per finger mode)
COMMUNICATION
Wi-Fi
- Yes (802.11 b/g/n)
Bluetooth®
- Built-in Bluetooth® (8m Range – For Mobile Applications)
Ethernet
- Yes (10/100 Mbps)
PoE
- Yes (IEEE 802.3 af)
RS-232
- Yes
Mobile Broadband
- Yes
Wiegand
- Wiegand IN/OUT Available
USB
- 1 Micro-USB Port (Data transfer and 2G-3G dongle)
INTERFACE
Exit Switch Port
- Yes
Door Status Sense
- Programmable NO, NC, Supervised
Door Lock Relay
- 30V DC @ 2 A, Form C, DPDT Relay
Door Lock Power
- 12V DC @ 0.5A (Power to external Lock from Device)
- 30V DC @2 A (Power to lock from External power source)
RS-232
- Yes
Wiegand
- Yes (Selectable IN/OUT)
- IN: 26 Bit format
- OUT: Configurable
Aux-In
- No
Aux-Out
- No
Reader Interface Types
- RS-232 and Wiegand IN/OUT
Micro SD Card
- Yes (Inbuilt 16GB)
HARDWARE
CPU
- 800 MHz ARM Cortex A8 based Processor
Memory
- 512 MB Flash + 512 MB DDR3 RAM
Display
- 3.5″ IPS Display with Capacitive Touch Panel with Gorilla Glass
Display Resolution
- 320 x 480 Pixel
Buzzer
- Yes
Operating Temperature
- 0°C to +50°C (32°F to 122°F)
Humidity
- 5% to 95% RH Non-Condensing
Thermal Sensor
- Yes, Built-in to Indicate Overheat Conditions
Tamper Detection
- Yes
Power
- 12V DC @ 2A
Power to Door Lock
- 12V DC @ 0.5A (Power to external Lock from Device)
Dimensions (WxHxD)
- Wall Mount: 74mm x 186mm x 50mm
- Flush Mount: 74mm x 186mm x 16mm
Weight
- 0.550Kgs (1.21Lbs)
COMPATIBILITY
System Integration
- API for Software Integration
Operational Modes
- Direct Door with COSEC CENTRA / COSEC VYOM
- Panel Door with COSEC PANEL200P
USB
- Yes (USB 2.0)
- Micro USB-Type B
SENSOR
Sensor Name
- Suprema Optical Sensor – SFM6030
Sensor Technology
- Optical Technology
Encryption
- Encryption
EER
- <0.08%
Resolution (dpi)
- 500
Sensing Area
- 16.0mm x 18.0mm
Template Size
- 384 bytes
Image Size (Pixel)
- 288 x 288
INSTALLATION
Wall Mount
- Yes – Plastic Back Cover with Screws
Flush Mount
- Yes – Metal Bracket with Screws
ACCESSORIES
Power Adapter
- 12VDC @ 2A (CE, FCC, UL, BIS)
Can’t Find What You’re Looking For?
Don’t worry, we’re here to assist you. Sometimes, finding the perfect solution can be a bit tricky, but we’re committed to assisting you every step of the way.
Our Solutions
Video Surveillance
Time-Attendance
Access Control
Telecom Solution
Fill out the form below, our team will get in touch with you shortly.
We appreciate your interest in our products and services. For product inquiries, please fill in the relevant details or you can forward your inquiry on Inquiry@MatrixComSec.com.
"*" indicates required fields
"*" indicates required fields
Technical Specifications
VIDEO
Input
- 4/8/16 IP Channels
Output
- HDMI (2.0) – 1 Port (Main)
Compression
- H.265/H.264/ Motion JPEG
AUDIO
Compression
- G.711µ
THROUGHPUT
Downlink Throughput
- 180 Mbps
The following Scenarios are Considered:
1. Cameras Streaming to Device
2. Cameras of Cascaded Devices being Viewed on HDMI
3. Streaming from NAS for local/web client
Downlink Throughput
- 213 Mbps
The following scenarios are considered:
1. Cameras Streaming to Device
2. Cameras of Cascaded Devices being Viewed on HDMI
3. Recording in Local HDDs, No NAS Connectivity
Uplink Throughput
- 180 Mbps
The following scenarios are considered:
1. Cameras streaming to the web client
2. Storage or backup to NAS
3. Streaming to VMS
Uplink Throughput
- 205 Mbps
The following scenarios are considered:
1. Cameras Streaming to Web Client
2. NVR streaming to cascaded NVRs/VMS
Simultaneous Log-in
- 9+1(Admin)
DISPLAY
Digital Zoom on Live
- Yes
Snapshot
- Yes
Multiple Camera Viewing
- Through Cascading (up to 20 Devices)
OSD
- Channel Number and Name, Status, Video Loss, Recording, and Disabled Channel (As per camera support)
RECORDING
Image Resolution
- 12MP, 8MP, 5MP,3MP, 2MP, 720P, D1, CIF
Pre-Record
- Up to 30 Sec
Post-Record
- 10-300 Sec
Snapshot Format
- JPEG
Recording Format
- AVI, Native
Recording Types
- Scheduled, Manual, Alarm, and COSEC
STORAGE AND BANDWIDTH OPTIMIZATION
Adaptive Recording
- Automatically Reduces the Number of Frames Captured per Second Where There is No Motion, Thereby Saving Storage Space.
Bandwidth Optimization
- Automatically Adapts Optimized Resolution on Local Display Through HDMI
PLAYBACK AND BACKUP
Synchronous Playback
- 16 Channels @ 1080P (via HDMI)
Search Mode
- Date and Time, Camera, Recording Type, Recording Drive
Backup
- Manual Backup over USB and NAS,
- Scheduled Backup over USB, NAS and FTP
- Scheduled Backup over USB through USB 2.0 interface
- Manual Backup over USB through USB 3.0 interface
- Quick Backup over USB, NAS and Local PC
Configuration Backup
- Yes
Network Protocols
- TCP/IP, DHCP, PPPOE, DDNS, Free Matrix DNS, FTP, SMTP, NTP, RTP/RTSP, CIFS/NFS, Network Acceleration, UDP
Maximum User
- 128
Remote Operation
- Monitor, PTZ Control, Playback, System Setting, File Download, Log Information, Upgrade
EVENTS AND ACTION
Trigger Events
- Motion Detection, View Tampering, Trip Wire, Object Intrusion, Audio Exception, Missing Object, Suspicious Object, Loitering, Object Counting, Recording Start, Recording Fail, Camera Offline, Camera Online
System Events
- Manual Trigger, On Boot Alarm, Storage Alert, Disk Volume Full, Disk Fault, Scheduled Backup Fail
Actions
- Recording on Selected Channel, Upload Images on FTP/ Email Server, Email Notification with Snapshot, TCP Notification, Recall PTZ Preset Position, Turn On/Off Alarm Outputs, Buzzer Notification, SMS Notification, Calling from Mobile App
STORAGE INTERFACE
SATA Interface
- 1 SATA III (10TB per port)
NAS
- 2 NAS (CIFS, NFS)
USB
- 1 TB USB DriveRAID
RAID
- Single Disk
Retention
- Camera-wise, HDD usage % wise, Day wise
INTERFACES
Network Interface
- 1 Port x Ethernet (RJ-45) 10/100/1000Mbps
USB
- 2 Ports (1x USB 3.0, 1x USB2.0)
LED
- System Status LED, Power LED
Reset Switch
- Yes
Buzzer
- Yes
SYSTEM INTERFACE
Processor
- Quad-core 64-bit Cortex-A55 processor
RAM
- 2GB
Flash
- 4GB
OS
- Embedded Linux
Control Mode
- Mouse, Web Client, and Mobile Client
CAMERA SUPPORT
Third Party Camera Support
- Cameras with ONVIF 2.0 and above
ENVIRONMENT CONDITIONS
Operating Temperature
- 0°C to +45°C (32°F to 104°F)
Humidity Range
- 5% to 95% RH Non-Condensing
ELECTRICAL AND MECHANICAL
Power Input
- Adapter 12V DC/2A
Dimension(L×B×H) in mm
- 266 X 157 X 44 mm
Weight (without hard disk)
- 490 gm approx
Technical Specifications
Functionality and Specifications
Deployment Architecture
- Centralized/ Distributed Management and Recording Components
Centralized Management and Control
- Yes
Operating System Platform
- Microsoft Windows
DBMS Support
- MS-SQL
Video Wall/ Multi-Display
- Yes
ONVIF Support
- Yes – Profile S. Profile G
Mobile App without Cost
- Yes – SATATYA VISION (Android and i-OS)
Multi User Login
- Allowed
Single User login on Different Client
- Allowed
Login Via SSL – Secure Socket Layer Login
- Yes
Retrieval of Password through OTP (SMS/ E-mail)
- Yes
E-mail and SMS Templates for Events and Action
- Yes (Default and Custom)
Creating Custom/ User defined Events/ Alerts
- Yes
Calling Custom Events through TCP and HTTP API
- Yes (Trigger)
Integrating COSEC and Custom Database
- Yes (For User and Vehicle Details)
Activity/ Events Logs
- Yes with Custom Search Criteria
License Management Configuration
- Yes
Device based License DongleSupport
- Yes (Dongle 200,Device Supported: COSEC VEGA or COSEC PANEL LITE V2)
Vehicle and User Attributes
- Yes (Add/ Edit/ Delete)
Failover Recording Server without additional cost
- Yes
Redundant Recording Server without additional License
- Yes
ONVIF RTSP Server without additional License
- Yes
Transcoding Server without additional License
- Yes
Server and Entity Connection with Dual ISP (Failover ISP Support)
- Yes – Support for 3 different networks
Local Network
Primary ISP
Secondary ISP
Applicable to Management Server, Recording Server, FailOver Server, IVA Server and Devices.
Fail-Over/ Redundant Server Support and Recording
- Yes
Local Drive Support
Device/ Entity wise redundancy
Playback Support
Playback Sync for Failover Server/ Redundant Recording Server
- Yes
Recording Server Configuration
- Yes
Enable/Disable Server
Assigning and Configuring the Devices (Recorders and IPC) to Server (Auto Discovery , Manually and Auto Add Matrix Devices)
Set up Storage, Recording and Backup
Location and Contact Information
Configuring Camera and Device
- Yes
Profile Setting
Stream Parameters and Stream Usage
Recording and Backup
Events
Basic Settings (OSD, Image Appearance)
Video Streaming and Recording Format
- H.265/ H.264/ MPEG-4/ MJPEG
HEVC/ H.265 Streaming over Onvif Protocol
- Yes (Server Onvif Version 17.06 and Above)
Storage
- Local Drives
Network Added Storage (NAS)
FTP Drive
Recording Type
- Continuous Recording
Manual Recording
Motion Recording
Event Recording
Adaptive Recording
- Yes
Device/ Edge Initiated Communication
- Yes (Support for Matrix Video Recorders and Matrix IPCs)
Backup and Archive
- Primary Backup with Two Level of Archive
Storage and Bandwidth Optimization
- Yes
Layout wise Resolution and Bandwidth Optimization in Live View
- Yes
Day Highlight and Clip Capture
- Yes
Time Lapse Solution and AVI Export
- Yes
Configuration Cloning
- Yes
System and Device Time Synchronization
- Yes (Over ONVIF)
Camera Grouping
- Yes
PTZ Positions and Tour Configuration
- Yes
On Screen PTZ Controller
- Yes
Hardware PTZ Controller Support
- Yes (USB)
Multiple IPC Export over Synchronous and Asynchronous Mode
- Yes
Video Export Format
- Native (Proprietary Format)/ AVI
Watermarking on Export
- Yes (Image/ Video)
Detection through Investigator
- Yes (Based on the IVA License)
E-Map/ Site-Map
- Yes (Server/ Devices/ IPC)
- Add Electronic Map (.jpg / .bmp Format
Multilevel
Place the Entity with different Appearance
Configure Event Notification
E-map through Live View Video Tile
- Yes
System Monitoring and Health Chart
- Yes (Server/ Devices/ IPC)
- Connected/ Not Connected Entity
Stream Receiving
CPU Usage/ Memory Usage/ Server Availability
Storage Usage and Projections
Recording Rate
Last and Latest Recording Files availability
User Logical View Tree – For Online Users
- Yes
Provision to mark Device Under Maintenance
- Yes with Mandatory Reason
COSEC Access Control Integration
- Yes
I/O Integration with Relay based Sensors
- Yes
System Setting
- Yes
- User Interface Level – Labels
Reports and Templates
Input
Multi Language Support
- Yes
- User Interface Level – Labels
Reports and Templates
Input
System Account User
- Accessibility wise User Rights (Add/ Edit/ Remove)
- Administrator
Operator
User
File Templates
- File Import/ Export
Schedules
Priority wise Alarms and Custom Alarms
API Integration for Third Party POS
- Yes (Supported as per API Document)
Four Simultaneous Stream support
- Yes – Live/ Local/ Recording/ Mobile
Multicast Stream Support
- Yes (Recording Server; Smart Client; IVA Server; Third Party Client)
64 Camera Video Template with different Matrix
- Yes
Personalize My View for Live and Page Sequence
- Yes
Dwell Time Configuration for IP camera
- Yes – 1 to 60 S
Individual IP camera level configuration
Client Bandwidth Optimization
- Yes
Using Bandwidth available – Yes (Transcoding)
As per Video tile occupied on Screen – Yes (Layout wise)
Event Log/ Activity Log and Export
- Yes
Two Way Audio
- Yes
Audio Broadcasting
- Yes
Third Party Client – Stream share
- Yes
Live View and Playback Data using RTSP Streaming Server
One Click IPC and Monitor Control on Client
- Yes
Alarm Management
- Yes – Generation/ Acknowledgement / Comment/ Close
Operator Generated Event/ Manual Event/ Trigger IVA
- Yes
Bookmark facility with Retention Lock
- Yes
Edge Recording
- Yes (512 GB at IPC End Matrix Project and Professional Series – 2/3/5 MP IPCs)
Edge Storage Retrieval and Playback sync
- Yes
Connection/ Schedule retrieval of Records
Video Pop up/ Email/ SMS/ Snapshot as Live Notification
- Yes
Reports with Multi Language Support
- Yes
UI Personalization
- Yes – Custom Logo on Client Screens and Video Export
Report Personalization
- Yes – Custom Logo and Font Size
Advance Report with Report Scheduler
- Yes
Report with Video Clip Hyperlink – Thumbnail and Images
- Yes
Technical Specifications
IMAGE SENSOR
Resolution
- 2 MP (1920 x 1080)
Sensor Type and Size
- 1/2.8″ SONY – CMOS 2MP Active Pixel
- Progressive Scan, Back-Illuminated Image sensor (STARVIS Series)
LENS
Minimum Illumination
- Color – 0.01 Lux @F1.2 (AGC ON)
- Monochrome – 0 Lux
Focal Length
- 2.8mm, 3.6mm, 6mm
Focus Range
- 0.3m to infinity
Field of View (FOV)
-
2.8mm 3.6mm 6mm HFOV 106.9° 87.6° 54° VFOV 56.9° 46.4° 29.03° DFOV 127.9° 104.5° 62.96°
Lens Mount
- For Fixed Lens: M12
Focus
- Fixed for 2.8mm,3.6mm, 6mm
Aperture (F#)
- Fixed Lens: F 1.6/ F2.0
Iris Type
- Fixed Lens: Fixed
IR Range
- Up to 30m
IR Led Wavelength
- 850nm
IR Switching
- Auto/ Manual
AUDIO INTERFACE
Audio IN
- NA
Audio OUT
- NA
Two-way Audio
- NA
Audio Compression
- NA
Alarm In
- NA
Alarm Out
- NA
HARDWARE SPECIFICATIONS
SD Card
- Not Supported
Camera Adjustment Angle
- Pan – 0° to 360°
- Tilt – 0° to 75°
- Rotate – 0° to 360°
IMAGE AND VIDEO
No. of Stream Profiles
- 4
Stream Profiles
- Profile 1: 1920x1080p(2MP) @30fps (H.265/ H.264)
Profile 2: D1 @30fps (H.265/H.264)
Profile 3: 1080p/720p/D1/2CIF/CIF @5fps (MJPEG) or 720p/D1/2CIP/CIF@15fps(H.264/H.265)
Profile 4: 720p/D1/2CIF/CIF @ 30 fps (H.265/H.264/MJPEG)
Available Resolutions
- 1920 x 1080, 720p, D1,2CIF, CIF, VGA
Max Resolution
- 1920 x 1080
Bitrate
- 128 kbps-8Mbps
Bitrate Type
- CBR, VBR
Video Compression
- H.265, H.264, MJPEG
Frame Rate
- 1-30fps
Shutter Speed
- 1/15s -1/100000s (in Upcoming Release)
Adaptive Streaming
- Yes
ONVIF Profiles
- S, G and T
Edge Recording
- Yes only in NAS
Alarm Recording
- Pre (30 sec) and Post(300 sec)
Motion Recording
- Yes
Time-triggered
- Yes
Video Parameters
- Snapshot, Region of Interest (ROI), BLC, Day/Night Settings
Privacy Masks
- 3
WDR
- True WDR (120dB)
SNR
- >70dB
Image Enhancement
- Saturation/ Contrast/ Sharpness/Brightness/Auto Exposure/HVS-Forensics/ Smart IR
DNR
- 2D &3D
Video Analytics
- Motion/No Motion Detection, View Tamper Detection, Trip/No Trip Detection, Object Intrusion/Zone Intrusion
ALERTS
IP Conflict
- Yes
Network Disconnect
- Yes
Storage Full
- Yes
EVENTS AND ACTIONS
Upload Image
- NAS, SFTP
Upload Clip
- NAS, SFTP
Notifications
- E-mail, SMS, TCP
PROTOCOLS SUPPORTED
Supported protocols
- TCP/IP, HTTP,ARP, HTTPS, DHCP, QoS, DHCP, DNS, DDNS, RTP, RTCP, RTSP, PPPOE, SMTP, NTP, HTTPS, , TLS/SSL, SFTP, ICMP, IGMP, 802.1x, SNMP, UPnP, Bonjour,UDP
Web Viewer
- Supported in IE 8.0-11.0, Firefox 15.0-47.0, Chrome 20.0-54.0
Browser
- IE, Chrome, Mozilla
CYBER SECURITY
Secure boot
- Yes
Signed firmware
- Yes
Data Encryption
- All data, including sensitive data, is encrypted with AES 256 and RSA 2048
IP Address Filtering
- Yes
HTTPs Streaming
- Yes, using TLS 1.2
Edge Data Encryption
- Yes
Network Authentication
- Yes,802.1x Network authentication
Secure Firmware Upgrade
- Yes
Anti-roll back firmware
- Yes
Web login Password protection
- Yes
Unused debug interface protection
- Yes
OPERATING PARAMETERS
Power Supply
- 802.3af (PoE)
Power Consumption
- Approximately 5W
Operating Humidity
- Less than 95% RH (non-condensing)
Operating Temperature
- -30°C to 60°C
Storage Temperature
- -35°C to 60°C
PHYSICAL PARAMETERS
Communication interface
- 10Base-T/100BaseTX Ethernet (RJ-45)
Weight
- 720gms
Color
- Infinity White
Dimensions
- Φ138.58 mm x 118.97 mm (Diameter x Height)
Storage
- NAS
Certifications
- BIS, CE, IP67, FCC Part-15 Subpart – B, ONVIF S G and T, STQC Certified with OWASP ASVS 4.0 L2
Technical Specifications
IMAGE SENSOR
Resolution
- 2 MP (1920 x 1080)
Sensor Type and Size
- 1/2.8″ SONY – CMOS 2MP Active Pixel
Progressive Scan, Back-Illuminated Image sensor (STARVIS Series)
LENS
Minimum Illumination
- Color – 0.01 Lux @F1.2 (AGC ON)
Monochrome – 0 Lux
Focal Length
- 2.8mm, 3.6mm, 6mm
Focus Range
- 0.5m to infinity
Field of View (FOV)
-
2.8mm 4mm 6mm HFOV 107.6° 57° 127.62° VFOV 87° 46.4° 104.5° DFOV 54.3° 29.2° 63°
Lens Mount
- M12
Aperture (F#)
- F1.6
Iris Type
- Fixed Lens
IR Range
- Up to 30m
IR Led Wavelength
- 850nm
IR Switching
- Auto/ Manual
AUDIO INTERFACE
Audio IN
- Built-In Microphone
Audio OUT
- 1x(3.5mm screw-type audio jack)
Two-way Audio
- Supported
Audio Compression
- G.726, G.711µ, G.722
Alarm In
- Yes
Alarm Out
- Yes
HARDWARE SPECIFICATIONS
SD Card
- Up to 512GB
Camera Adjustment Angle
- Pan – 30° to +30°
Tilt – 10° to 90°
Rotate +/-175°
IMAGE AND VIDEO
No. of Stream Profiles
- 4
Stream Profiles
- Profile 1:- 1080p(2MP)/720p/D1/VGA/2CIF/CIF/QCIF upto 60 fps(H.265/H.264)
Profile 2:- D1/2CIF/CIF/QCIF upto 30fps(H.265/H.264)
Profile 3:- 1080p(2MP)/720p/D1/2CIF/CIF/QCIF/VGA upto 5 fps(MJPEG)
Profile 4:- 720p/D1/2CIF/VGA/CIF/QCIF upto 30 fps(H.265/H.264)
Available Resolutions
- 1920 x 1080, 720p, D1,2CIF, CIF, QCIF,VGA
Max Resolution
- 1920 x 1080
Bitrate
- 128 kbps-8Mbps
Bitrate Type
- CBR, VBR
Video Compression
- H.265, H.264, MJPEG
Frame Rate
- 1-60fps
Shutter Speed
- 1/15s-1/100000s
Adaptive Streaming
- Yes
ONVIF Profiles
- S,G and T
Edge Recording
- Yes
Alarm Recording
- Pre and Post
Motion Recording
- Yes
Time Triggered
- Yes
Video Parameters
- Snapshot, Region of Interest (ROI), BLC, Day/Night Settings
Privacy Masks
- 8
WDR
- True WDR (120dB)
SNR
- >70dB
Image Enhancement
- Saturation/ Contrast/ Sharpness/Brightness/Auto Exposure/HVS-Forensics/ Smart IR
DNR
- 2D &3D
Video Analytics
- Motion/No Motion Detection, Tamper Detection, Trip/No Trip Detection, Object Intrusion/Zone Intrusion, Audio Exception
ALERTS
IP Conflict
- Yes
Network Disconnect
- Yes
Storage Full
- Yes
EVENTS AND ACTIONS
Upload Image
- SD, NAS, SFTP
Upload Clip
- SD, NAS, SFTP
Notifications
- E-mail, SMS, TCP
PROTOCOLS SUPPORTED
Supported protocols
- TCP/IP, HTTP, HTTPs, QoS, DHCP, DNS, DDNS, RTP, RTCP, RTSP, PPPOE, SMTP, NTP, TLS/SSL, SFTP, ICMP, IGMP, ARP, UDP, 802.1x, SNMP, UPnP, Bonjour
Web Viewer
- Supported in IE 8.0-11.0, Firefox 15.0-47.0, Chrome 20.0-54.0
Browser
- IE, Chrome, Mozilla
CYBER SECURITY
Secure boot
- Yes
Signed firmware
- Yes
Data Encryption
- All data, including sensitive data, is encrypted with AES 256 and RSA 2048
IP Address Filtering
- Yes
HTTPs Streaming
- Yes, using TLS 1.2
Edge Data Encryption
- Yes
Network Authentication
- Yes,802.1x Network authentication
Secure Firmware Upgrade
- Yes
Anti-roll back firmware
- Yes
Web login Password protection
- Yes
Unused debug interface protection
- Yes
OPERATING PARAMETERS
Power Supply
- 12V (DC); 802.3af (PoE)
Power Consumption
- 3.3 – 7W
Operating Humidity
- 5-95% RH (non-condensing)
Operating Temperature
- -30°C to 60°C
PHYSICAL PARAMETERS
Communication interface
- 10Base-T/100BaseTX Ethernet (RJ-45)
Weight
- 700g
Color
- Infinity White
Dimensions
- 120.5×118.6×63.3 mm
(Length x Width x Height)
Storage
- NAS, SD Card
Certifications
- BIS, CE, FCC Part-15 Subpart–B, IK10, NEMA4X, STQC Certified with OWASP ASVS 4.0 L2
Technical Specifications
CAMERA
Image Sensor
- 1/ 2.8” CMOS
Signal System
- PAL/ NTSC
Minimum Illumination
- Color: 0.001lux @F1.5, BW 0lux with IR
Shutter Speed
- 1s – 1/100000s
Day & Night
- IR Cut Filter with Auto Switch
Wide Dynamic Range
- 140dB
Optical Zoom
- 25x
Digital Zoom
- 16x
LENS
Focal Length
- 4.8mm – 120mm
Zoom Speed
- <4s
Angle of View
- Horizontal: 58.5° – 2.8°
Vertical: 33.2° – 1.5°
Aperture Range
- F1.5 – F3.8
PAN & TILT
Pan Range
- 360°
Pan Speed
- Pan Manual Speed: 0.1°/s – 200°/s; Pan Preset Speed 240°/s
Tilt Range
- -15° – 90° (Auto Flip)
Tilt Speed
- Tilt Manual Speed: 0.1°/s – 120°/s; Tilt Preset Speed: 180°/s
3D Position
- Yes
Presets
- 500
Preset Accuracy
- ±0.4°
Scan
- 8
Cruise
- 16, up to 32 preset per cruise
Pattern
- 8, each with 600s memory
Power Off Memory
- Yes
ILLUMINATOR
IR LED
- 6
IR Range
- Up to 150m
IR irradiance Angle
- Adjustable by Zoom
COMPRESSION STANDARD
Video Compression
- H.265/ H.264/ M-JPEG
Video Bitrate
- 32Kbps – 16Mbps
Audio Compression
- G.711a, G.711µ, ADPCM, AAC_LC
Audio Bitrate
- 8kbps- 48kbps
Max Resolution
- 1920×1080
Mainstream
- PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480)
- NTSC: 30fps (1920×1080, 1280×720, 704×480, 640×480)
Sub Stream
- PAL: 25fps (704×576, 704×288, 640×360, 352×288)
- NTSC: 30fps (704×480, 704×240, 640×360, 352×240)
Third Stream
- PAL: 25fps (352×288)
- NTSC: 30fps (352×240)
Image Setting
- Saturation, brightness, contrast, sharpness (Adjustable by web browser)
Image Enhancement
- BLC/3D DNR/HLC
ROI
- 7 Dynamic Areas for both Main and Sub Stream
OSD
- 16X16, 32X32,48X48,64X64,96X96
Total 5 Regions
Picture Overlay
- Yes
Privacy Mask
- 24
Smart Defog
- Yes
FEATURE
Alarm Trigger
- Motion Detection, Network Disable Alarm, IP Conflict, MAC Conflict Detection
Video Analytics
- Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Video Abnormal, Audio Abnormal
Auto Tracking
- N/A
NETWORK
Protocol
- TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTSP, PPPoE, NTP, UPnP, SMTP, IGMP, QoS, IPv4, IPv6, Multicast, SNMP,802.1x
System Compatibility
- ONVIF Ready
Remote Connection
- ≤7
INTERFACE
Communication Interface
- 1 RJ45 10/100 Self Adaptive Ethernet Port
Audio
- 1/1
Alarm
- 1/1
Reset Button
- Yes
On Board Storage
- Built-in Micro SD card slot up to 256GB
GENERAL
Webpage Language
- 15 Languages
Operating Conditions
- (-40°C) – 70°C (IR off), (-40°C) – 40°C (IR on)
Power Supply
- DC 12V/ POE
Power Consumption
- 10.7W (IR off); 21W (IR on)
Certification
- IP66, ONVIF, BIS, IK10
Heater
- Yes
Dimension
- Φ161x276mm (Φ6.34×10.87 inch)
Weight
- 2.9 Kg
Technical Specifications
IMAGE SENSOR
Resolution
- 2 MP (1920 x 1080)@30fps
Sensor Type and Size
- 1/2.8″ SONY – CMOS 2MP Active Pixel
- Progressive Scan, Back-Illuminated Image sensor (STARVIS Series)
LENS
Minimum Illumination
- Color – 0.01 Lux @F1.2 (AGC ON)
- Monochrome – 0 Lux
Focal Length
- 2.8mm, 3.6mm, 6mm
Focus Range
- 0.3m to infinity
Field of View (FOV)
-
2.8mm 3.6mm 6mm HFOV 106.9° 87.5° 54° VFOV 56.9° 44.4° 29.03° DFOV 127.9° 104.9° 62.96°
Lens Mount
- For Fixed Lens: M12x0.5
Focus
- Fixed for 2.8mm, 3.6mm, 6mm
Aperture (F#)
- Fixed Lens: F 1.6/ F2.0
Iris Type
- Fixed Lens: Fixed
IR Range
- Up to 30m
IR Led Wavelength
- 850nm
IR Switching
- Auto/ Manual
AUDIO INTERFACE (ONLY FOR PREMIUM VARIANTS)
Audio Streaming
- Two-way Audio (full duplex)
Audio Input
- 1x (3.5mm stereo female audio jack) (for Premium Variants)
Audio Output
- 1x (3.5mm stereo female audio jack) (For Premium Variants)
Audio IN Impedance
- Linear level impedance 1kohm
Audio OUT Impedance
- Linear level impedance 600ohm
Audio Noise Filtering
- Yes
Audio Sampling rate
- 8 KHz
Audio Compression
- G.726, G.711 a-law and u-law
HARDWARE SPECIFICATIONS
SD Card
- Up to 512GB
Camera Adjustment Angle
- Pan – 0° to 330°
Tilt – 0° to 75°
Rotate – 0° to 180°
IMAGE AND VIDEO
No. of Stream Profiles
- 4
Stream Profiles
- Profile 1: 1920 x 1080p @30fps (H.265/H.264)
Profile 2: D1 @30fps (H.265/H.264)
Profile 3: 1920 x 1080p @5fps (MJPEG)
Profile 4: 720p @30fps (H.265/H.264/MJPEG)
Available Resolutions
- 1920 x 1080, 720p, D1,2CIF, CIF, VGA
Max Resolution
- 1920 x 1080
Bitrate
- 128 kbps-8Mbps
Bitrate Type
- CBR, VBR
Video Compression
- H.265, H.264, MJPEG
Frame Rate
- 1-30fps
Shutter Speed
- 1/15s -1/100000s
Adaptive Streaming
- Yes
ONVIF Profiles
- Both S and G
Edge Recording
- Yes
Alarm Recording
- Pre and Post
Motion Recording
- Yes
Time-triggered
- Yes
Video Parameters
- Snapshot, Region of Interest (ROI), BLC, Day/Night Settings
Privacy Masks
- 3
WDR
- True WDR (120dB)
SNR
- 71dB
Image Enhancement
- Saturation/ Contrast/ Sharpness/Brightness/Auto Exposure/HVS-Forensics/ Smart IR
DNR
- 3D
Video Analytics
- Motion, Tamper Detection, Trip/No Trip Detection, Object Intrusion/Zone Intrusion, Audio Exception (Only Premium Variants)
ALERTS
IP Conflict
- Yes
Network Disconnect
- Yes
Storage Full
- Yes
EVENTS AND ACTIONS
Upload Image
- SD, NAS, SFTP
Upload Clip
- SD, NAS, SFTP
Notifications
- E-mail, SMS, TCP
PROTOCOLS SUPPORTED
Supported protocols
- TCP/IP, HTTP,ARP, HTTPS, DHCP, QoS, DHCP, DNS, DDNS, RTP, RTCP, RTSP, PPPOE, SMTP, NTP, HTTPS, , TLS/SSL, SFTP, ICMP, IGMP, 8021x, SNMP, UPnP, Bonjour,UDP
Web Viewer
- Supported in IE 8.0-11.0, Firefox 15.0-47.0, Chrome 20.0-54.0
Browser
- IE, Chrome, Mozilla
CYBER SECURITY
Secure boot
- Yes
Signed firmware
- Yes
Data Encryption
- All data, including sensitive data, is encrypted with AES 256 and RSA 2048
IP Address Filtering
- Yes
HTTPs Streaming
- Yes, using TLS 1.2
Edge Data Encryption
- Yes
Network Authentication
- Yes,802.1x Network authentication
Secure Firmware Upgrade
- Yes
Anti-roll back firmware
- Yes
Web login Password protection
- Yes
Unused debug interface protection
- Yes
OPERATING PARAMETERS
Power Supply
- 12V (DC); 802.3af (PoE)
Power Consumption
- Approximately 7W
Operating Humidity
- Less than 95% RH (non-condensing)
Operating Temperature
- -30°C to 60°C
Storage Temperature
- -30°C to 60°C
PHYSICAL PARAMETERS
Communication interface
- 10Base-T/100BaseTX Ethernet (RJ-45)
Weight
- 740gms
Color
- Infinity White
Dimensions (mm)
- Diameter Φ126 x Length 100
Storage
- NAS, SD Card
Certifications
- BIS, CE, IP67, FCC Part-15 Subpart – B, ONVIF S G & T, IK10, STQC Certified with OWASP ASVS 4.0 L2
Technical Specifications
IMAGE SENSOR
Resolution
- 2 MP (1920 x 1080)
Sensor Type and Size
- 1/2.8″ SONY – CMOS 2MP Active Pixel
Progressive Scan, Back-Illuminated Image sensor (STARVIS Series)
LENS
Minimum Illumination
- Color – 0.01 Lux @F1.2 (AGC ON)
Monochrome – 0 Lux
Focal Length
- 2.8mm, 3.6mm, 6mm
Focus Range
- 0.3m to infinity
Field of View (FOV)
-
2.8mm 3.6mm 6mm 2.8mm-12mm VL/MVL HFOV 107° 87.5° 54° 98°-33° VFOV 57° 44.4° 29° 51°-19° DFOV 128° 105° 63° 116°-38°
Lens Mount
- Fixed Lens: M12x0.5
Manual Varifocal Lens: M14
Motorized Varifocal Lens: M14
Focus
- Fixed for 2.8mm,3.6mm, and 6mm
Manual Varifocal Iris for VL
Motorized Varifocal Iris for MVL
Aperture (F#)
- Fixed Lens: F 1.6/ F2.0
Varifocal Lens: F1.6-F3.2.
Motorized Varifocal Lens: F1.6-F3.2
Iris Type
- Fixed Lens: Fixed
Manual Varifocal Iris for VL
Motorized Varifocal Iris for MVL
IR Range
- Up to 50m
IR Led Wavelength
- 850nm
IR Switching
- Auto/ Manual
AUDIO INTERFACE
Audio IN
- 1, 3.5mm Audio Jack (For Premium Variants)
Audio OUT
- 1, 3.5mm Audio Jack (For Premium Variants)
Two-way Audio
- Supported
Audio Compression
- G.726 and G.711µ
Alarm In
- Yes Phoenix type (For Premium Variants)
Alarm Out
- Yes Phoenix type (For Premium Variants)
HARDWARE SPECIFICATIONS
SD Card
- Up to 512GB
Camera Adjustment Angle
- Pan – 0° to 330°
Tilt – 0° to 75°
Rotate – 0° to 180°
IMAGE AND VIDEO
No. of Stream Profiles
- 4
Stream Profiles
- Profile 1: 1080p(2MP)/720p/D1/2CIF/CIF up to 30 fps (H.265/H.264)
Profile 2: D1/2CIF/CIF up to 30fps (H.265/H.264)
Profile 3: 1080p(2MP)/720p/D1/2CIF/CIF up to 5 fps (MJPEG)
Profile 4: 720p/D1/2CIF/CIF up to 30 fps (H.265/H.264/MJPEG)
Available Resolutions
- 1920 x 1080, 720p, D1,2CIF, CIF, VGA
Max Resolution
- 1920 x 1080
Bitrate
- 128 kbps-8Mbps
Bitrate Type
- CBR, VBR
Video Compression
- H.265, H.264, MJPEG
Frame Rate
- 1-30fps
Shutter Speed
- 1/15s -1/100000s
Adaptive Streaming
- Yes
ONVIF Profiles
- Both S, G & T
Edge Recording
- Yes
Alarm Recording
- Pre and Post
Motion Recording
- Yes
Time Triggered
- Yes
Video Parameters
- Snapshot, Region of Interest (ROI), BLC, Day/Night Settings
Privacy Masks
- 3
WDR
- True WDR (120dB)
SNR
- 71dB
Image Enhancement
- Saturation/ Contrast/ Sharpness/Brightness/Auto Exposure/HVS-Forensics/ Smart IR
DNR
- 2D &3D
Video Analytics
- Motion
Tamper Detection
Trip/No Trip Detection
Object Intrusion/Zone Intrusion
Audio Exception
ALERTS
IP Conflict
- Yes
Network Disconnect
- Yes
Storage Full
- Yes
EVENTS AND ACTIONS
Upload Image
- SD, NAS, SFTP
Upload Clip
- SD, NAS, SFTP
Notifications
- E-mail, SMS, TCP
PROTOCOLS SUPPORTED
Supported protocols
- TCP/IP, HTTP, ARP, HTTPS, DSCP, QoS, DHCP, DNS, DDNS, RTP, RTCP, RTSP, PPPOE, SMTP, NTP, HTTPS, TLS/SSL, SFTP, ICMP, IGMP, 802.1x, SNMP, UPnP, Bonjour,UDP
Web Viewer
- Supported in IE 8.0-11.0, Firefox 15.0-47.0, Chrome 20.0-54.0
Browser
- IE, Chrome, Mozilla
CYBER SECURITY
Secure boot
- Yes
Signed firmware
- Yes
Data Encryption
- All data, including sensitive data, is encrypted with AES 256 and RSA 2048
IP Address Filtering
- Yes
HTTPs Streaming
- Yes, using TLS 1.2
Edge Data Encryption
- Yes
Network Authentication
- Yes,802.1x Network authentication
Secure Firmware Upgrade
- Yes
Anti-roll back firmware
- Yes
Web login Password protection
- Yes
Unused debug interface protection
- Yes
OPERATING PARAMETERS
Power Supply
- 12V (DC); 802.3af (PoE)
Power Consumption
- Approximately 7W
Operating Humidity
- Less than 95% RH (non-condensing)
Operating Temperature
- -30°C to 60°C
Storage Temperature
- -30°C to 60°C
PHYSICAL PARAMETERS
Communication interface
- 10Base-T/100BaseTX Ethernet (RJ-45)
Weight
- 1.41 Kgs
Color
- Infinity White
Dimensions
- Dimensions (mm): Diameter Φ158 x Length 134
Storage
- NAS, SD Card
Certifications
- BIS, CE, IP67, FCC Part-15 Subpart – B, ONVIF S G & T, IK10, UL, NEMA 4X**, STQC Certified with OWASP ASVS 4.0 L2
Technical Specifications
IMAGE SENSOR
Resolution
- 2 MP (1920 x 1080)
Sensor Type and Size
- 1/2.8″ SONY – CMOS 2MP Active Pixel
- Progressive Scan, Back-Illuminated Image sensor (STARVIS Series)
LENS
Minimum Illumination
- Color – 0.01 Lux @F1.2 (AGC ON)
- Monochrome – 0 Lux
Focal Length
- 2.8mm
- 3.6mm
- 6mm
Focus Range
- 0.3m to infinity
Field of View (FOV)
-
2.8mm 3.6mm 6mm HFOV 106.9° 84° 51.26° VFOV 56.9° 47.8° 28.84° DFOV 127.9° 96.4° 58.74°
Lens Mount
- Fixed Lens: M12x0.5
Focus
- Fixed for 2.8mm – 3.6mm – 6mm
Aperture (F#)
- Fixed Lens: F 1.6/ F2.0
Iris Type
- Fixed Lens: Fixed
IR Range
- Up to 30m
IR Led Wavelength
- 850nm
IR Switching
- Auto/ Manual
AUDIO INTERFACE
Audio Streaming
- Two-way Audio (full duplex)
Audio Input
- 1x (3.5mm stereo female audio jack) (for Premium Variants)
Audio Output
- 1x (3.5mm stereo female audio jack) (For Premium Variants)
Audio IN Impedance
- Linear level impedance 1kohm
Audio OUT Impedance
- Linear level impedance 600ohm
Audio Noise Filtering
- Yes
Audio Sampling rate
- 8 KHz
Audio Compression
- G.726, G.711 a-law and u-law
HARDWARE SPECIFICATIONS
SD Card
- Up to 512GB
Camera Adjustment Angle
- Pan – 0° to 330°
Tilt – 0° to 75°
Rotate – 0° to 180°
IMAGE AND VIDEO
Stream Profiles
- Profile 1:- 1080p(2MP)/720p/D1/2CIF/CIF upto 30 fps(H.265/H.264)
Profile 2:- D1/2CIF/CIF upto 30fps(H.265/H.264)
Profile 3:- 1080p(2MP)/720p/D1/2CIF/CIF upto 5 fps(MJPEG)
Profile 4:- 720p/D1/2CIF/CIF upto 30 fps(H.265/H.264/MJPEG)
No. of Stream Profiles
- 4
Available Resolutions
- 1920 x 1080
- 720p
- D1
- 2CIF
- CIF
- VGA
Max Resolution
- 1920 x 1080
Bitrate
- 128 kbps-8Mbps
Bitrate Type
- CBR
- VBR
Video Compression
- H.265
- H.264
- MJPEG
Frame Rate
- 1-30fps
Shutter Speed
- 1/15s -1/100000s
Adaptive Streaming
- Yes
ONVIF Profiles
- Both S and G
Edge Recording
- Yes
Alarm Recording
- Pre and Post
Motion Recording
- Yes
Time-Triggered
- Yes
Video Parameters
- Snapshot
- Region of Interest (ROI)
- BLC
- Day/Night Settings
Privacy Masks
- 3
WDR
- True WDR (120dB)
SNR
- 71dB
Image Enhancement
- Saturation
- Contrast
- Sharpness
- Brightness
- Auto Exposure
- HVS-Forensics
- Smart IR
DNR
- 3D
Video Analytics
- Motion Detection
Tamper Detection
Trip/No Trip Detection
Object Intrusion/Zone Intrusion
Audio Exception ( Premium Variants)
ALERTS
IP Conflict
- Yes
Network Disconnect
- Yes
Storage Full
- Yes
EVENTS AND ACTIONS
Upload Image
- SD
- NAS
- SFTP
Upload Clip
- SD
- NAS
- SFTP
Notifications
- SMS
- TCP
PROTOCOLS SUPPORTED
Supported protocols
- TCP/IP
- HTTP
- ARP
- HTTPS
- DHCP
- QoS
- DHCP
- DNS
- DDNS
- RTP
- RTCP
- RTSP
- PPPOE
- SMTP
- NTP
- TLS/SSL
- SFTP
- ICMP
- IGMP
- 8021x
- SNMP
- UPnP
- Bonjour
- UDP
Web Viewer
- Supported in IE 8.0-11.0
- Firefox 15.0-47.0
- Chrome 20.0-54.0
Browser
- IE
- Chrome
- Mozilla
CYBER SECURITY
Secure boot
- Yes
Signed firmware
- Yes
Data Encryption
- All data, including sensitive data, is encrypted with AES 256 and RSA 2048
IP Address Filtering
- Yes
HTTPs Streaming
- Yes, using TLS 1.2
Edge Data Encryption
- Yes
Network Authentication
- Yes,802.1x Network authentication
Secure Firmware Upgrade
- Yes
Anti-roll back firmware
- Yes
Web login Password protection
- Yes
Unused debug interface protection
- Yes
OPERATING PARAMETERS
Power Supply
- 12V (DC); 802.3af (PoE)
Power Consumption
- Approximately 5.5W
Operating Humidity
- Less than 95% RH (non-condensing)
Operating Temperature
- -30°C to 60°C
Storage Temperature
- -30°C to 60°C
PHYSICAL PARAMETERS
Communication interface
- 10Base-T/100BaseTX Ethernet (RJ-45)
Weight
- 500gms
Color
- Infinity White
Dimensions
- 155 mm x 75 mm (Length x Diameter)
Storage
- NAS
- SD Card
Certifications
- BIS, CE, IP67, FCC Part-15 Subpart – B, ONVIF S & G, IK10, STQC Certified with OWASP ASVS 4.0 L2
Technical Specifications
IMAGE SENSOR
Resolution
- 2 MP (1920 x 1080)
Sensor Type and Size
- 1/2.8″ SONY – CMOS 2MP Active Pixel Progressive Scan
- Back-Illuminated Image sensor (STARVIS Series)
LENS
Minimum Illumination
- Color – 0.01 Lux @F1.2 (AGC ON)
- Monochrome – 0 Lux
Focal Length
- 2.8mm
- 3.6mm
- 6mm
Focus Range
- 0.3m to infinity
Field of View (FOV)
-
2.8mm 3.6mm 6mm 2.8mm-12mm VL/MVL HFOV 106.9° 87.5° 54° 98°-33° VFOV 56.9° 44.4° 29.03° 51°-19° DFOV 127.9° 104.9° 62.96° 116°-38°
Lens Mount
- Fixed Lens: M12x0.5
Manual Varifocal Lens: M14
Motorized Varifocal Lens: M14
Focus
- Fixed for 2.8mm,3.6mm, 6mm
Manual Varifocal Iris for VL
Motorized Varifocal Iris for MVL
Aperture (F#)
- Fixed Lens: F 1.6/ F2.0
Varifocal Lens: F1.6-F3.2
Motorized Varifocal Lens: F1.6-F3.2
Iris Type
- Fixed Lens: Fixed
Varifocal Lens: F1.6-F3.2
Motorized Varifocal Lens: F1.6-F3.2
IR Range
- Up to 50m
IR Led Wavelength
- 850nm
IR Switching
- Auto/ Manual
AUDIO INTERFACE
Audio IN
- 1, 3.5mm Audio Jack (For Premium Variants)
Audio OUT
- 1, 3.5mm Audio Jack (For Premium Variants)
Two-way Audio
- Supported
Audio Compression
- G.726 and G.711µ
Alarm In
- Yes Phoenix type (For Premium Variants)
Alarm Out
- Yes Phoenix type (For Premium Variants)
HARDWARE SPECIFICATIONS
SD Card
- Up to 512GB
Camera Adjustment Angle
- Pan – 0° to 360°, Tilt – 0° to 90°,Rotate – 0° to 360°
IMAGE AND VIDEO
No. of Stream Profiles
- 4
Stream Profiles
- Profile 1: 1080p(2MP)/720p/D1/2CIF/CIF up to 30 fps (H.265/H.264)
Profile 2: D1/2CIF/CIF up to 30fps (H.265/H.264)
Profile 3: 1080p(2MP)/720p/D1/2CIF/CIF up to 5 fps (MJPEG)
Profile 4: 720p/D1/2CIF/CIF up to 30 fps (H.265/H.264/MJPEG)
Available Resolutions
- 1920 x 1080, 720p, D1,2CIF, CIF, VGA
Max Resolution
- 1920 x 1080
Bitrate
- 128 kbps-8Mbps
Bitrate Type
- CBR, VBR
Video Compression
- H.265, H.264, MJPEG
Frame Rate
- 1-30fps
Shutter Speed
- 1/15s -1/100000s
Adaptive Streaming
- Yes
ONVIF Profiles
- S, G, and T
Edge Recording
- Yes
Alarm Recording
- Pre and Post
Motion Recording
- Yes
Time Triggered
- Yes
Video Parameters
- Snapshot, Region of Interest (ROI), BLC, Day/Night Settings
Privacy Masks
- 3
WDR
- True WDR (120dB)
SNR
- 71dB
Image Enhancement
- Saturation/ Contrast/ Sharpness/Brightness/Auto Exposure/HVS-Forensics/ Smart IR
DNR
- 2D &3D
Video Analytics
- Motion, Tamper Detection, Trip/No Trip Detection, Object Intrusion/Zone Intrusion
ALERTS
IP Conflict
- Yes
Network Disconnect
- Yes
Storage Full
- Yes
EVENTS AND ACTIONS
Upload Image
- SD, NAS, SFTP
Upload Clip
- SD, NAS, SFTP
Notifications
- E-mail, SMS, TCP
PROTOCOLS SUPPORTED
Supported protocols
- TCP/IP, HTTP, HTTPs, DSCP, QoS, DHCP, DNS, DDNS, RTP, RTCP, RTSP, PPPOE, SMTP, NTP, TLS/SSL, SFTP, ICMP, IGMP, ARP, UDP, 802.1x, SNMP,UPnP, Bonjour
Web Viewer
- Supported in IE 8.0-11.0, Firefox 15.0-47.0, Chrome 20.0-54.0
Browser
- IE, Chrome, Mozilla
CYBER SECURITY
Secure boot
- Yes
Signed firmware
- Yes
Data Encryption
- All data, including sensitive data, is encrypted with AES 256 and RSA 2048
IP Address Filtering
- Yes
HTTPs Streaming
- Yes, using TLS 1.2
Edge Data Encryption
- Yes
Network Authentication
- Yes,802.1x Network authentication
Secure Firmware Upgrade
- Yes
Anti-roll back firmware
- Yes
Web login Password protection
- Yes
Unused debug interface protection
- Yes
OPERATING PARAMETERS
Power Supply
- 12V (DC); 802.3af (PoE)
Power Consumption
- Approximately 7W
Operating Humidity
- Less than 95% RH (non-condensing)
Operating Temperature
- -30°C to 60°C
Storage Temperature
- -30°C to 60°C
PHYSICAL PARAMETERS
Communication interface
- 10Base-T/100BaseTX Ethernet (RJ-45)
Weight
- 840gms
Color
- Infinity White
Dimensions
- Diameter x Length: Φ84mmx301.6mm or
- Length: 301.6mm x 92.5mm x 84mm (Length x Width x Height)
Storage
- NAS, SD Card
Certifications
- BIS, CE, IP67, FCC Part-15 Subpart – B, ONVIF S,G, T, IK10, OWASP ASVS 4.0 L2 by STQC, NEMA 4x**
| Name | GSM/4G Ports | FXS Ports |
| SIMADO GFX11 | 1 (GSM) | 1 |
| SIMADO GFX11 4G | 1 (4G) | 1 |
| SIMADO GFX11E | 1 (GSM) | 1 |
| SIMADO GFX11E 4G | 1 (4G) | 1 |
| SIMADO GFX44 | 4 (GSM) Up to 3G | 4 |
| Name | VoIP Channels | FXS Ports | FXO Ports | SIP Accounts |
| SETU VFX404 | 4 | 4 | 0 | 9 |
| SETU VFX808 | 8 | 8 | 0 | 9 |
| SETU VFX440 | 4 | 0 | 4 | 9 |
| SETU VFX880 | 8 | 8 | 8 | 9 |
| SETU VFX844 | 8 | 4 | 4 | 9 |
| SETU VFXTH3200 | 32 | 0 | 32 | Upto 32 |
| SETU VFXTH0016 | 16 | 16 | 0 | Upto 32 |
| SETU VFXTH0024 | 24 | 24 | 0 | Upto 32 |
| SETU VFXTH0032 | 32 | 32 | 0 | Upto 32 |
| SETU VFXTH0808 | 16 | 8 | 8 | 16 |
| Name | T1/E1 Ports | SIP Trunks | VoIP-PRI Calls (Simultaneous) | Built-in VoIP Modules |
| SETU VTEP 4P | 4 | 125 | 120 | 2 |
| SETU VTEP 3P | 3 | 125 | 90 | 2 |
| SETU VTEP 2P | 2 | 125 | 60 | 1 |
| SETU VTEP 1P | 1 | 125 | 30 | 1 |
| System Resources | SARVAM UMG (ETERNITY GENX) Max. Resources |
| Universal Slots | 12 |
| SIP Trunks | 250 |
| VOIP Channels | 128 |
| NX DBM VOCODER64 | 2 |
| GSM/3G/4G Ports | 48 |
| T1/E1 PRI Ports | 8 |
| CO/FXO (TWT) Ports | 192 |
| SLT/FXS Ports | 240 |
| Max Concurrent IP-TDM Calls | 128 |
